What Is Line Voltage?

Line Voltage is the electrical potential supplied by a power source to a circuit, equipment, or building wiring system. Line voltage powers devices such as lighting, receptacles, motors, and heating equipment. The term distinguishes source voltage from lower control voltage used by thermostats, relays, doorbells, and similar control components.

Quick Facts About Line Voltage

Key Takeaways About Line Voltage

Line voltage powers equipment directly from the electrical supply.
Control voltage operates signals, switches, and low-power control circuits.
Line voltage is not the same as current or wattage.

How Line Voltage Works

A person holds a red wire and a small white component while reading a line voltage explanation on a tablet

Line Voltage moves electrical energy from a service panel or other supply point through conductors to a connected load. A meter or approved voltage tester checks the potential between selected conductors. The reading helps an electrician confirm whether a circuit receives power and whether the circuit matches the equipment design.

Related glossary terms: Electrical Load, Neutral Wire, Voltage Drop.

Line voltage appears at lighting outlets, receptacles, disconnects, and equipment connections. Control voltage may operate a relay or thermostat, while line voltage supplies the equipment that performs the main work. During electrical wiring installation, conductors, boxes, switches, and connections must suit the circuit and the intended load. Electrical load describes the power demand placed on that circuit, while a neutral wire provides a return path in applicable wiring systems.

Hands adjust wires inside a gray electrical box labeled LINE VOLTAGE beside a computer screen

From the Service Electric team

When we install wiring, we identify the line-voltage conductors and verify their connections at the panel, devices, and equipment. We also distinguish supply conductors from control wiring so each component receives the type of power it requires. Our team checks for unexpected voltage before working on an existing circuit.

Line Voltage in Practice: A Real-World Example

A homeowner adds a wall switch and ceiling light during an electrical wiring installation. Line voltage travels from the panel to the switch and light, while the switch controls when the fixture receives power.
